Display Specifications
Size 11.6-inch display with LED Backlight
Resolution 1920 x 1080 Full HD
Contrast Ratio 1000:1
Panel Brightness 850 nits with direct optical bonding for sunlight readability
Viewing Angle 89/89/89/89
Touch Projected capacitive multi-touch
Technology • Anti-glare technology (Default)
• Automatic screen rotation

System Specification
CPU Intel® Pentium® N4200 1.1GHz (Turbo up to 2.5 GHz)
System Memory 4GB LPDDR4 RAM 1 (up to 8GB)
Storage 128GB SSD (options up to 512GB)
Additional storage available with micro SDXC card slot
Graphics Intel® HD Graphics 504
Operating System Windows 10 IoT Enterprise (64 bit)
Sensors Light sensor/ g-sensor / Gyro / E-compass

Wireless Communication
WLAN 802.11 a/b/g/n/ac WiFi
Bluetooth Bluetooth 5.0
GNSS GPS, GLONASS
WWAN Optional 4G LTE

Interface
Docking Connector 1 x 19-pin docking connector
HDMI 1 x micro HDMI
USB 1 x USB 3.0 (Type A), 1 x USB 3.0 (Type C) 2
Power Input 1 x Power Jack
Micro SD 1 x Micro SDXC slot
Audio 1 x Audio combo connector (Mic in or Line Out)
LAN 1 x RJ45-10/100/1000 GigaLAN port (Optional)
Expansion Port 1 x Expansion connector for USB 2.0/ Full RS232 (Optional)
Micro SIM 1 x Micro SIM card slot
mini PCIe 1 x Mini PCIe for WWAN Module

Keyboard and Input
Physical Buttons 1 x Power; 3 x function keys
Touch 10-point multi-touch, supports Rain / Glove / Stylus Modes

Audio
Microphone Built-in dual digital mic with noise cancellation
Speaker 2 x 1 watt front-facing speakers

Cameras
Front Camera 2MP front camera
Rear Camera 8MP rear camera with autofocus and LED light

Data Capture
Integrated Optional 1D/2D Barcode Reader
Optional HF RFID reader 13.56 MHz
Optional Smart Card Reader
Add-on Module Optional add-on UHF RFID Reader or Smart Card Reader

Security Function
Security • Trusted Platform Module (TPM) 2.0
• Kensington Lock
Mobile Device Mgmt. SOTI Mobicontrol compatible

Certificate
• CE, FCC

Mechanical and Environment
Dimensions (W x L x H) 300.67 x 201.97 x 22.5 mm
Weight 1.35 kg
Operating Temperature -20°C to 60°C (AC mode), -10°C to 50°C (Battery mode)
Storage Temperature -30°C to 70°C
Operating Humidity 10% to 90% RH, non-condensing
Shock MIL-STD-810G Method 516.6 Procedure I
Vibration MIL-STD-810G Method 514.6 Procedure I
Drop MIL-STD-810G Method 516.6, 4 ft to concrete
IP Rating IP65 certified, dustproof and waterproof

Power Management
Power Input 19V DC
AC Adapter 100-240V, 50-60Hz (19V DC)
Battery Hot-swappable 7.7V typ. 5900 mAh Li-Polymer Battery (2S1P)
Optional 7.4V typ. 10280 mAh Li-Polymer Battery (2S2P)
Battery Operating Time Std. Battery: 8 hours

Standard Accessories
• Adapter and Power Cord
• Capacitive Stylus
• Standard Battery

Optional Accessories
• Desk Dock
• Vehicle Dock
• Vehicle Charger
• Battery Charger
• Smart Card Reader
• UHF RFID Reader
• High Capacity Battery
• Hand Strap
• VESA Mount Kit
• Shoulder Strap
• Carry Bag
• Micro HDMI Cable
• USB-C to Ethernet Adapter
• USB-C to RS232 Adapter
• USB-C to USB-A Hub
