A Rugged Tablet that Can Survive Any Environment and Get Real Work Done

M700DQ8 is a compact rugged tablet PC with robust set of features designed to withstand industrial use while providing high tech solutions that increase productivity, improve safety, and reduce operational costs. The processing power comes from Qualcomm® Snapdragon™ 660, Octa-core up to 2.2 GHz. The tablet features a brilliant, in-plane switching with projected capacitive touch screen and offers 1280 x 720 pixel resolution. Weighing at just 1.2 pounds (approx. 550 grams) the M700DQ8 delivers lightweight mobility in a pocket-sized rugged tablet.

Features:

Qualcomm® Snapdragon™ 660, Octa-core up to 2.2 GHz

7” 1280 x 720 TFT Panel with direct optical bonding

Supports Android 9.0 OS

IP65 waterproof and dustproof

Rated for extreme temperature use

Display Specifications
Size 7”
Brightness 650 (typ.)
Resolution 1280 x 720
Touch Projected Capacitive Multi-Touch

System Specification
Processor Qualcomm® Snapdragon™ 660, Octa-core, up to 2.2 GHz
Memory 3GB RAM
Storage 32GB eMMC

Wireless Communication
WLAN 802.11 a/b/g/n/ac
Bluetooth Bluetooth 5.0
WWAN Optional 4G LTE
GPS GPS / AGPS / GLONASS

I/O Connectors
Audio 2 x Built-in Mic
1 x 1.2 W speaker
1 x Earphone
External I/O 1 x docking connector
1 x USB Type C
1 x Power Jack
1 x Micro SD Card Slot
1 x SIM Card Slot

Mechanical and Environment
Dimensions (W x L x H) 212.4 x 132.8 x 19 mm
Net Weight (kg) 550g
Operating Temperature -20°C to 60°C (AC mode), -10°C to 50°C (Battery mode)
IP Proof IP65
Operating Humidity 5%-95% RH (non-condensing)
Shock MIL-STD-810G Method 516.6 Procedure
Vibration MIL-STD-810G Method 514.6 Procedure
Drop MIL-STD-810G Method 516.6, 5 ft to concrete

Power Management
Power Input 5V DC
Battery 3.7V 5300 mAh Li-Poly
Adapter 100-240V/ 5V 3A Adapter

Product Specification
OS Android 9.0
Camera 8MP Front Camera; 13MP Rear Camera with LED auxilliary light (auto focus)
